FAG 22226E1K.C3 Spherical Roller Bearing

Manufacturer: Schaeffler FAG

Type: Spherical Roller Bearing with tapered bore

Model: 22226 E1K.C3

Replaces: 22226-E1-XL-K-C3, 22226-E1-K-C3

Dimensions:

Bore Diameter d: 130 mm

Outer diameter D: 230 mm

Width: 64 mm

Bore type: Tapered, taper 1:12

Dynamic load rating: 760000 N

Static load rating: 890000 N

Fatigue load limit: 81000 N

limiting speed: 3350 RPM

Reference speed: 2500 RPM

Radial internal clearance: Group 3 (C3)

Cage material: Sheet metal cage

Operating temperature: -30 … +200 °C
