FAG 22230-E1-K-C3 Spherical Roller Bearing

Manufacturer: Schaeffler FAG

Type: Spherical Roller Bearing with tapered bore

Model: 22230 E1-K-C3

Replaces: 22230-E1-XL-K-C3, 22230E1K.C3

Dimensions:

Bore Diameter d: 150 mm

Outer diameter D: 270 mm

Width: 73 mm

Bore type: Tapered, taper 1:12

Dynamic load rating: 1010000 N

Static load rating: 1210000 N

Fatigue load limit: 114000 N

limiting speed: 2900 RPM

Reference speed: 2050 RPM

Radial internal clearance: Group 3 (C3)

Cage material: Sheet metal cage

Operating temperature: -30 … +200 °C
