FAG 22312-E1A-M-C3 Spherical Roller Bearing

Manufacturer: Schaeffler FAG

Type: Spherical roller bearing

Model: 22312 E1A-M-C3

Replaces: 22312-E1A-XL-M-C3, 22312E1A.M.C3

Dimensions:

Bore Diameter d: 60 mm

Outer diameter D: 130 mm

Width: 46 mm

Dynamic load rating: 310000 N

Static load rating: 310000 N

Fatigue load limit: 29000 N

limiting speed: 5400 RPM

Reference speed: 4200 RPM

Radial internal clearance: Group 3 (C3)

Cage material: Solid brass cage

Operating temperature: -30 … +200 °C
