FAG 22313EK Spherical Roller Bearing

Manufacturer: FAG
Type: Spherical Roller Bearing
Model: 22313 EK

Dimensions
Bore Diameter d: 65 mm
Outer diameter D: 140 mm
Width B: 48 mm
Basic load ratings, radial:
Dynamic C_r: 350000 N
Static C_0r: 365000 N
Fatigue load limit, radial: 33500 N
Limiting Speed: 5000 rpm
Reference speed: 3800 rpm
Design: E1, without central rip
Cage material: Sheet metal cage
Bore type: K, Tapered, taper 1:12
Operating temperature: -30 … +200 °C
