FAG 2307 K.TV.C3 Self-Aligning Ball Bearing
New
In stock1 unitReady to ship
Self-Aligning Ball Bearing
The FAG 2307 K.TV.C3 Self-Aligning Ball Bearing features a 35mm bore, 80mm outer diameter, and 31mm width, with a C3 clearance and tapered bore for high-performance applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 2307 K.TV.C3 Self-Aligning Ball Bearing
The FAG 2307 K.TV.C3 Self-Aligning Ball Bearing is designed for high-performance industrial applications, offering superior load capacity and self-alignment capabilities. With a tapered bore and C3 radial internal clearance, this bearing ensures efficient operation under varying load conditions.
Manufacturer: FAG
Type: Self-Aligning Ball Bearing
Model: 2307 K.TV.C3
| Bore Diameter (d) | 35 mm |
| Outer Diameter (D) | 80 mm |
| Width | 31 mm |
| Dynamic Load Rating | 40,500 N |
| Static Load Rating | 11,200 N |
| Fatigue Load Limit | 710 N |
| Limiting Speed | 8,900 1/min |
| Reference Speed | 9,800 1/min |
| Bore | K, Tapered, Taper 1:12 |
| Radial Internal Clearance | C3 |
| Cage | TV, Solid Cage Made of Glass-Fiber Reinforced Polyamide PA66 |
