FAG 3202-BD-2HRS-TVH Double ROW Angular Contact Ball Bearing
New
In stock17 unitsReady to ship
15,55$
Double Row Angular Contact Ball Bearing
FAG 3202-BD-2HRS-TVH Double Row Angular Contact Ball Bearing features a 15 mm bore and 35 mm outer diameter, with a contact angle of 30° for precise radial and axial load handling. Designed with a glass-fiber reinforced polyamide PA66 cage and 2HRS sealing for reliable performance.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 3202-BD-2HRS-TVH Double Row Angular Contact Ball Bearing
The FAG Double Row Angular Contact Ball Bearing 3202-BD-2HRS-TVH is designed for high-precision applications requiring support for both radial and axial loads. With a contact angle of 30°, it offers reliable performance in dynamic environments.
Manufacturer: FAG
Type: Double Row Angular Contact Ball Bearing
Model: 3202-BD-2HRS-TVH
| Bore Diameter (d) | 15 mm |
| Outer Diameter (D) | 35 mm |
| Width (B) | 15.9 mm |
| Contact Angle | 30° |
| Dynamic Load Rating (Cr) | 12,600 N |
| Static Load Rating (C0r) | 7,400 N |
| Fatigue Limit Load (Cur) | 520 N |
| Limiting Speed | 16,700 1/min |
| Cage Design | TVH, Solid cage made of glass-fiber reinforced polyamide PA66 |
| Sealing | 2HRS, Contact seal on both sides |
