Bearings Rolling Bearings Angular Contact

FAG 3202-BD-XL-2HRS-TVH Double ROW Angular Contact Ball Bearing

Name: FAG 3202-BD-XL-2HRS-TVH DOUBLE ROW ANGULAR CONTACT BALL BEARING
SKU: 1076489
Price: 15.55 USD
Availability: InStock

fag-3202-BD-XL-2HRS-TVH-double-row-angular-contact-ball-bearing-new-carton

fag-3202-BD-XL-2HRS-TVH-double-row-angular-contact-ball-bearing-new-carton-1

New

In stock10 unitsReady to ship

15,55$

Double Row Angular Contact Ball Bearing

FAG 3202-BD-XL-2HRS-TVH Double Row Angular Contact Ball Bearing features a 15 mm bore diameter, 35 mm outer diameter, and 15.9 mm width. It offers high load ratings, 16,700 rpm speed, and enhanced sealing for reliable performance in heavy-duty applications.

Manufacturer

FAG

SKU

1076489

Category

Angular Contact

Condition

New

12 15 2HRS 3202-BD-XL 3202-BD-XL-2HRS-TVH 600 Angular Ball bearing bore Contact Double Dynamic Fag High-Speed Load mm N Rating Row Sealed

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

FAG 3202-BD-XL-2HRS-TVH Double Row Angular Contact Ball Bearing

The FAG 3202-BD-XL-2HRS-TVH Double Row Angular Contact Ball Bearing is designed for high precision and durability, offering optimal performance under heavy loads and high speeds, with a unique sealing and cage design for reliability.

Manufacturer: FAG

Type: Double Row Angular Contact Ball Bearing

Model: 3202-BD-XL-2HRS-TVH

Bore Diameter (d)	15 mm
Outer Diameter (D)	35 mm
Width (B)	15.9 mm
Contact Angle	30 °
Dynamic Load Rating (Cr)	12,600 N
Static Load Rating (C0r)	7,400 N
Fatigue Limit Load (Cur)	520 N
Limiting Speed	16,700 1/min
Cage Design	TVH, Solid cage made of glass-fiber reinforced polyamide PA66
Sealing	2HRS, Contact seal on both sides
