FAG 3207B.TVH Double ROW Angular Contact Ball Bearing
Manufacturer: Schaeffler FAG
Type: Double Row Angular Contact Ball Bearing
Model: 3207 B.TVH
Dimensions
Bore Diameter d: 35 mm
Outer diameter D: 72 mm
Width B: 27 mm
Contact angle: 30 °
Basic load ratings:
Dynamic Cr: 41000 N
Static C0r: 30000 N
Fatigue load limit Cur: 2090 N
Limiting speed: 10100 rpm
Reference speed: 9900 rpm
Cage: TVH, solid cage made of glass-fiber reinforced polyamid PA66
