FAG 3304B.TVH Angular Contact Ball Bearing

In stock1 unitReady to ship

Angular Contact Ball Bearing

FAG 3304B.TVH double row angular contact ball bearing with 30° contact angle, polyamide cage, and high load capacity for industrial applications.

Manufacturer
FAG
SKU
1089993
Condition
New
Share
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed

FAG 3304B.TVH Double Row Angular Contact Ball Bearing

The FAG 3304B.TVH is a double row angular contact ball bearing designed to support combined radial and axial loads with high operational stability. Its optimized internal geometry and robust cage design ensure reliable performance in demanding industrial applications.

Manufacturer: FAG / Schaeffler

Type: Double Row Angular Contact Ball Bearing

Model: 3304B.TVH

Bore Diameter (d)20 mm
Outer Diameter (D)52 mm
Width (B)22.2 mm
Contact Angle30°
Dynamic Load Rating (Cr)24,600 N
Static Load Rating (C0r)15,900 N
Fatigue Load Rating1,100 N
Limiting Speed11,000 rpm
CageTVH, Solid Cage Made of Glass-Fiber Reinforced Polyamide PA66
Design VariantB, Bearing Without Filling Slot
