FAG 3308B.2RSR.TVH Double ROW Angular Contact Ball Bearing
New
In stock6 unitsReady to ship
Double Row Angular Contact Ball Bearing
FAG 3308B.2RSR.TVH Double Row Angular Contact Ball Bearing with 40 mm bore and 90 mm outer diameter. It offers a dynamic load rating of 67,000 N and a fatigue limit load of 3,350 N, designed for high-speed applications with a 30° contact angle.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 3308B.2RSR.TVH Double Row Angular Contact Ball Bearing
The FAG Double Row Angular Contact Ball Bearing 3308B.2RSR.TVH is engineered to support both radial and axial loads in high-speed applications. With robust dynamic and static load ratings, it is designed for reliable performance in demanding environments.
Manufacturer: FAG
Type: Double Row Angular Contact Ball Bearing
Model: 3308B.2RSR.TVH
| Bore Diameter (d) | 40 mm |
| Outer Diameter (D) | 90 mm |
| Width (B) | 36.5 mm |
| Contact Angle | 30 ° |
| Dynamic Load Rating (Cr) | 67,000 N |
| Static Load Rating (C0r) | 48,500 N |
| Fatigue Limit Load (Cur) | 3,350 N |
| Limiting Speed | 6,000 1/min |
| Cage Design | TVH, Solid cage made of glass-fiber reinforced polyamide PA66 |
| Sealing | 2RSR, Contact seal on both sides |
