FAG 6004-C-2Z Deep Groove Ball Bearing
New
In stock12 unitsReady to ship
Deep Groove Ball Bearing
The FAG 6004 C 2Z is a high-performance deep groove ball bearing with a 20 mm bore diameter and 42 mm outer diameter. It features a steel sheet metal cage, non-contact shields on both sides, and operates at high speeds up to 23,200 1/min.202Z426004BallbearingboreCCageDeepdiameterFagGrooveHigh-SpeedMetalmmNon-ContactOutersheetShieldSteel
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 6004 C 2Z “ Deep Groove Ball Bearing
The FAG 6004 C 2Z deep groove ball bearing is designed for high-speed operations and low-friction performance. With a durable steel sheet metal cage and a non-contact shield on both sides, it provides excellent protection against contaminants and offers reliable performance across a broad range of applications.
Manufacturer: FAG
Type: Deep Groove Ball Bearing
Model: 6004 C 2Z
| Bore Diameter (d) | 20 mm |
| Outer Diameter (D) | 42 mm |
| Width (B) | 12 mm |
| Dynamic Load Rating (Cr) | 10,600 N |
| Static Load Rating (C0r) | 5,000 N |
| Fatigue Load Limit | 340 N |
| Limiting Speed | 23,200 1/min |
| Reference Speed | 19,700 1/min |
| Cage | Steel sheet metal |
| Sealing | 2Z, non-contact shield on both sides |
| Operating Temperature | -20 to 120°C |
