FAG 6200-C-2Z Deep Groove Ball Bearing
New
In stock23 unitsReady to ship
Deep Groove Ball Bearing
The FAG 6200 C 2Z deep groove ball bearing features a 10 mm bore and steel sheet metal cage, designed for high-speed applications with a dynamic load rating of 7,000 N and a wide operating temperature range from -20 to 120°C.000102Z62007BallbearingboreCCageDeepDynamicFagGrooveHigh-SpeedLoadMetalmmNNon-ContactRatingsheetShieldSteel
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 6200 C 2Z “ Deep Groove Ball Bearing
The FAG 6200 C 2Z is a high-quality deep groove ball bearing designed to handle radial and axial loads with high speed capability. Built for longevity, this bearing features non-contact shields and operates efficiently under a wide temperature range.
Manufacturer: FAG
Type: Deep Groove Ball Bearing
Model: 6200 C 2Z
| Bore Diameter (d) | 10 mm |
| Outer Diameter (D) | 30 mm |
| Width (B) | 9 mm |
| Dynamic Load Rating (Cr) | 7,000 N |
| Static Load Rating (C0r) | 2,600 N |
| Fatigue Load Limit | 181 N |
| Limiting Speed | 34,500 1/min |
| Reference Speed | 26,000 1/min |
| Cage | Steel sheet metal |
| Sealing | 2Z, non-contact shield on both sides |
| Operating Temperature | -20 to 120 degrees Celsius |
