FAG 6202-C-2Z-C3 Deep Groove Ball Bearing
New
Available on request
Deep Groove Ball Bearing
The FAG 6202C2ZC3 deep groove ball bearing features a 15 mm bore and 35 mm outer diameter, with non-contact shields and a steel sheet metal cage. It offers reliable, high-speed performance with a dynamic load rating of 8,900 N and an operating temperature range from -20 to 120°C.15356202C2ZC3BallbearingboreC3CageClearanceDeepdiameterFagGrooveHigh-SpeedmmNon-ContactOuterShieldSteel
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 6202C2ZC3 “ Deep Groove Ball Bearing
The FAG 6202C2ZC3 deep groove ball bearing is a high-quality component designed for versatile and durable performance in a wide range of mechanical applications. With a steel sheet metal cage and non-contact shields, this bearing is ideal for environments requiring high-speed rotation and reliability.
Manufacturer: FAG
Type: Deep Groove Ball Bearing
Model: 6202C2ZC3
| Bore Diameter (d) | 15 mm |
| Outer Diameter (D) | 35 mm |
| Width (B) | 11 mm |
| Dynamic Load Rating (Cr) | 8,900 N |
| Static Load Rating (C0r) | 3,750 N |
| Fatigue Load Limit | 260 N |
| Limiting Speed | 28,000 1/min |
| Reference Speed | 21,900 1/min |
| Cage | Steel sheet metal |
| Sealing | 2Z, non-contact shield on both sides |
| Clearance | C3 |
| Operating Temperature | -20 to 120°C |
