FAG 6208-C-2Z-C3 Deep Groove Ball Bearing
New
Available on request
Deep Groove Ball Bearing
FAG 6208-C-2Z-C3 Deep Groove Ball Bearing features a 40 mm bore diameter, 80 mm outer diameter, and 18 mm width. It offers a dynamic load rating of 33,500 N, with shielded protection on both sides and a C3 clearance for high performance in demanding applications.33405006208-C-2Z-C380BallbearingboreC3ClearanceDeepdiameterDynamicFagGrooveIndustrialLoadmmNOuterShielded
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 6208-C-2Z-C3 Deep Groove Ball Bearing
The FAG 6208-C-2Z-C3 Deep Groove Ball Bearing is designed for high performance, featuring a robust steel sheet metal cage and shielding on both sides to protect against dirt and moisture.
Manufacturer: FAG
Model: 6208-C-2Z-C3
Type: Deep Groove Ball Bearing
| Bore Diameter (d) | 40 mm |
| Outer Diameter (D) | 80 mm |
| Width (B) | 18 mm |
| Dynamic Load Rating (Cr) | 33,500 N |
| Static Load Rating (C0r) | 17,800 N |
| Fatigue Load Limit | 1,230 N |
| Limiting Speed | 11,600 1/min |
| Reference Speed | 10,500 1/min |
| Cage | Steel sheet metal |
| Sealing | 2Z, Shielded on both sides |
| Clearance | C3 |
