FAG 6217MA.C3 Deep Groove Ball Bearing
New
In stock1 unitReady to ship
Deep Groove Ball Bearing
High-quality FAG 6217MA.C3 deep groove ball bearing with solid brass cage and C3 clearance, designed for high load capacity and reliable performance.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 6217MA.C3 Deep Groove Ball Bearing
The FAG 6217MA.C3 Deep Groove Ball Bearing from Schaeffler is a high-performance bearing designed for durability, reliability, and efficient rotational operation. It is suitable for a wide range of industrial applications requiring high load capacity and stable performance at various speeds.
Manufacturer: FAG / Schaeffler
Type: Deep Groove Ball Bearing
Model: 6217MA.C3
| Bore Diameter d | 85 mm |
| Outer Diameter D | 150 mm |
| Width B | 28 mm |
| Dynamic Load Rating (Cr) | 89000 N |
| Static Load Rating (C0r) | 64000 N |
| Fatigue Load Limit | 4.050 N |
| Limiting Speed | 8.800 rpm |
| Reference Speed | 5.300 rpm |
| Cage | MA, Solid Brass Cage |
| Radial Internal Clearance | C3 |
| Recommendation | Ideal choice for heavy-duty industrial applications requiring high reliability, extended service life, and consistent rotational performance. |
