FAG 6307-2Z Deep Groove Ball Bearing
New
In stock2 unitsReady to ship
Deep Groove Ball Bearing
FAG Schaeffler 6307-2Z Deep Groove Ball Bearing features a 35 mm bore diameter and 80 mm outer diameter. With a dynamic load rating of 35,500 N and a limiting speed of 10,500 1/min, it’s ideal for high-performance applications.355006307-2Z80BallbearingboreDeepdiameterDynamicFagGrooveLoadmmNNon-ContactOuterradialRatingSchaefflerShield
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG Schaeffler Deep Groove Ball Bearing 6307-2Z
The FAG Schaeffler 6307-2Z Deep Groove Ball Bearing is designed to offer high durability and smooth operation, with an enhanced load capacity and reliability in a variety of industrial applications.
Manufacturer: FAG Schaeffler
Type: Deep Groove Ball Bearing
Model: 6307-2Z
| Bore Diameter (d) | 35 mm |
| Outer Diameter (D) | 80 mm |
| Width (B) | 21 mm |
| Basic Dynamic Load Rating, Radial | 35,500 N |
| Basic Static Load Rating, Radial | 19,100 N |
| Fatigue Load Limit, Radial | 1,290 N |
| Limiting Speed | 10,500 1/min |
| Reference Speed | 9,900 1/min |
| Sealing | 2Z, Non-contact shield on both sides |
| Cage | Steel sheet metal |
