FAG 6309-2Z Deep Groove Ball Bearing
New
In stock1 unitReady to ship
Deep Groove Ball Bearing
FAG 6309-2Z single row deep groove ball bearing with steel cage, double metal shields, and high load capacity for industrial applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 6309-2Z Deep Groove Ball Bearing
The FAG 6309-2Z is a single row deep groove ball bearing designed for reliable operation, high load capacity, and stable rotational performance in industrial applications.
Manufacturer: FAG / Schaeffler
Type: Single Row Deep Groove Ball Bearing
Model: 6309-2Z
Please contact us via Ask for assistance with any inquiries.
| Bore Diameter (d) | 45 mm |
| Outer Diameter (D) | 100 mm |
| Width | 25 mm |
| Dynamic Load Rating | 56,000 N |
| Static Load Rating | 31,500 N |
| Fatigue Limit Load | 2,240 N |
| Limiting Speed | 8,100 1/min |
| Reference Speed | 8,200 1/min |
| Cage Material | Steel Sheet Metal |
| Sealing | 2Z, Non-contact Shield on Both Sides |
