FAG 7204-B-TVP-UO Angular Contact Ball Bearing
New
In stock3 unitsReady to ship
Angular Contact Ball Bearing
FAG 7204-B-TVP-UO Angular Contact Ball Bearing with 20 mm bore, 47 mm outer diameter, and a 40° contact angle. It offers a dynamic load rating of 14.9 kN and is designed for high-speed applications with speeds up to 21,600 rpm.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 7204-B-TVP-UO Angular Contact Ball Bearing
The FAG 7204-B-TVP-UO Angular Contact Ball Bearing is engineered for high-speed applications and precision handling. Its UO design ensures a clearance-free bearing set in O or X arrangement, making it ideal for demanding industrial applications.
Manufacturer: FAG
Type: Angular Contact Ball Bearing
Model: 7204-B-TVP-UO
| Design | UO, Bearing set clearance-free in O or X arrangement |
| Bore Diameter | 20 mm |
| Outer Diameter | 47 mm |
| Width | 14 mm |
| Contact Angle | 40° |
| Dynamic Load Rating (Cr) | 14.9 kN |
| Static Load Rating (C0r) | 7.8 kN |
| Fatigue Load Rating | 540 N |
| Limiting Speed | 21,600 rpm |
| Reference Speed | 15,400 rpm |
| Cage | TVP; Solid cage made of glass-fiber reinforced polyamide PA66 |
