FAG 7205-B-XL-TVP-UO Angular Contact Ball Bearing
New
In stock6 unitsReady to ship
Angular Contact Ball Bearing
FAG 7205-B-XL-TVP-UO Angular Contact Ball Bearing features a 25 mm bore diameter, 52 mm outer diameter, and 15 mm width. It operates at a 40° contact angle, designed for high-speed and high-precision industrial applications with a limiting speed of 19,200 1/min.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 7205-B-XL-TVP-UO Angular Contact Ball Bearing
The FAG Angular Contact Ball Bearing 7205-B-XL-TVP-UO is designed for high-precision applications requiring high-speed operation. With a contact angle of 40° and a solid cage made of glass-fiber reinforced polyamide PA66, this bearing ensures smooth and efficient performance in various industrial settings.
Manufacturer: FAG
Type: Angular Contact Ball Bearing
Model: 7205-B-XL-TVP-UO
| Design | UO, Bearing set clearance-free in O or X arrangement |
| Bore Diameter | 25 mm |
| Outer Diameter | 52 mm |
| Width | 15 mm |
| Contact Angle | 40° |
| Dynamic Load Rating (Cr) | 16,200 N |
| Static Load Rating (C0r) | 9,000 N |
| Fatigue Load Rating | 620 N |
| Limiting Speed | 19,200 1/min |
| Reference Speed | 13,700 1/min |
| Cage | TVP; Solid cage made of glass-fiber reinforced polyamide PA66 |
