FAG 7308B.MP.UA Angular Contact Ball Bearing

Manufacturer: FAG
Type: Angular Contact Ball Bearing
Model: 7308 B.MP.UA
Replaces: 7308-B-XL-MP-UA, 7308-B-MP-UA

Dimensions
Bore Diameter d: 40 mm
Outer diameter D: 90 mm
Width B: 23 mm
Basic load ratings:
Dynamic C_r: 57000 N
Static C_0r: 34500 N
Fatigue load limit C_ur: 2390 N
Contact Angle: 40°
Limiting speed: 13500 rpm
Reference speed: 7100 rpm
Cage: MP, solid brass cage, ball guided
Bearing with matched conditions for fitting in pairs: UA, bearing set with small axial internal clearance
