FAG 7310-B-MP-UA Angular Contact Ball Bearing
New
In stock18 unitsReady to ship
Angular Contact Ball Bearing
FAG / Schaeffler 7310-B-MP-UA single row angular contact ball bearing with 40° contact angle, 50 mm bore, solid brass cage, P6 tolerance, and matched bearing set with small axial internal clearance.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG / Schaeffler 7310-B-MP-UA Angular Contact Ball Bearing
The FAG / Schaeffler 7310-B-MP-UA is a single row angular contact ball bearing designed for applications requiring high load capacity, precise axial guidance, and reliable performance at elevated speeds. It is supplied as a matched bearing set with controlled axial internal clearance and a solid brass cage for enhanced durability.
Manufacturer: FAG / Schaeffler
Type: Single Row Angular Contact Ball Bearing
Model: 7310-B-MP-UA
| Bore Diameter (d) | 50 mm |
| Outer Diameter (D) | 110 mm |
| Width (B) | 27 mm |
| Contact Angle | 40° |
| Basic Dynamic Load Rating (Cr) | 80,000 N |
| Basic Static Load Rating (C0r) | 50,000 N |
| Fatigue Load Limit (Radial) | 3,500 N |
| Limiting Speed | 10,900 rpm |
| Reference Speed | 6,100 rpm |
| Cage | Solid Brass Cage, Ball Guided |
| Tolerance Class | Class 6 (P6) |
| Matched Condition | Bearing Set With Small Axial Internal Clearance |
| Operating Temperature Range | -30 °C To +150 °C |
