FAG 7312-B-MP-UA Angular Contact Ball Bearing
New
In stock1 unitReady to ship
Angular Contact Ball Bearing
FAG 7312-B-MP-UA angular contact ball bearing with 60 mm bore, 40° contact angle, solid brass cage, and matched bearing set design. Rated for high dynamic loads and operating temperatures from -30 °C to +150 °C.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 7312-B-MP-UA Angular Contact Ball Bearing
The FAG 7312-B-MP-UA angular contact ball bearing is designed for applications requiring high load capacity, precise axial guidance, and reliable performance at elevated speeds. Manufactured by Schaeffler, this bearing features a 40° contact angle and matched bearing set configuration for controlled axial clearance.
Manufacturer: FAG / Schaeffler
Type: Angular Contact Ball Bearing
Model: 7312-B-MP-UA
| Bore Diameter (d) | 60 mm |
| Outer Diameter (D) | 130 mm |
| Width (B) | 31 mm |
| Contact Angle | 40° |
| Dynamic Load Rating (Cr) | 96,000 N |
| Static Load Rating (C0r) | 69,000 N |
| Fatigue Load Limit (Radial) | 4,750 N |
| Limiting Speed | 9,200 rpm |
| Reference Speed | 5,300 rpm |
| Cage | Solid Brass Cage, Ball Guided |
| Tolerance Class | Normal (PN) |
| Matched Condition | Bearing Set With Small Axial Internal Clearance |
| Axial Clearance Per Set (Min.) | 46 Microns |
| Tolerance For Axial Clearance / Preload Per Set | 12 Microns |
| Operating Temperature Range | -30 °C To +150 °C |
