FAG 7312B.TVP Angular Contact Ball Bearing
New
In stock1 unitReady to ship
Angular Contact Ball Bearing
FAG / Schaeffler 7312-B-TVP angular contact ball bearing with 60 mm bore diameter, 40° contact angle, high dynamic load capacity, and polyamide cage. Designed for high-speed and combined load industrial applications.407312-B-TVPAngleAngularBallbearingCageContactDegreeFagHighIndustrialPolyamidePrecisionSchaefflerSpeed
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG / Schaeffler 7312-B-TVP Angular Contact Ball Bearing
The FAG / Schaeffler 7312-B-TVP is an angular contact ball bearing designed to support combined radial and axial loads. With a 40° contact angle and high load ratings, it is suitable for demanding industrial applications requiring precision, reliability, and high-speed performance.
Manufacturer: FAG / Schaeffler
Type: Angular Contact Ball Bearing
Model: 7312-B-TVP
Load Ratings
Speed Ratings
Additional Specifications
| Bore Diameter (d) | 60 mm |
| Outer Diameter (D) | 130 mm |
| Width (B) | 31 mm |
| Contact Angle | 40 Degrees |
| Basic Dynamic Load Rating (Cr) | 96,000 N |
| Basic Static Load Rating (C0r) | 69,000 N |
| Fatigue Load Limit, Radial | 4,750 N |
| Limiting Speed | 7,000 rpm |
| Reference Speed | 5,300 rpm |
| Cage | Solid Cage Made Of Glass-Fiber Reinforced Polyamide PA66 |
| Tolerance Class | Normal (PN) |
| Operating Temperature | -30 To 120 °C |
