FAG 7602025TVP Axial Angular Contact Ball Bearing
New
In stock1 unitReady to ship
Axial Angular Contact Ball Bearing
FAG 7602025TVP precision axial angular contact ball bearing with 25 mm bore, high radial load capacity, and TVP plastic cage for stable high-performance operation. Recommended for machine tool spindles and precision drive applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 7602025TVP Axial Angular Contact Ball Bearing
The FAG 7602025TVP axial angular contact ball bearing, manufactured by Schaeffler, is engineered for high axial and radial load capacity in precision industrial applications.
Manufacturer: FAG / Schaeffler
Type: Axial Angular Contact Ball Bearing
Model: 7602025TVP
Suitable for high-precision machine tools, spindle units, and industrial drive systems requiring reliable axial positioning and load support.
Please contact us via Ask for assistance with any inquiries.
| Bore Diameter | 25 mm |
| Outside Diameter | 52 mm |
| Width | 15 mm |
| Basic Dynamic Load Rating, Radial | 23,200 N |
| Basic Static Load Rating, Radial | 50,000 N |
| Fatigue Load Limit, Radial | 2,280 N |
| Limiting Speed | 8,000 1/min |
| Cage | TVP, Plastic Cage |
