FAG NN3036ASK.M.SP Double ROW Cylindrical Roller Bearing
New
In stock1 unitReady to ship
Double Row Cylindrical Roller Bearing
The FAG NN3036ASK.M.SP is a high-precision cylindrical roller bearing with a 180mm bore, brass cage, tapered bore, and SP tolerance class for high-speed applications.180mmbearingborebrassCageCylindricalDoubleFaghigh-precisionHigh-SpeedIndustrialNN3036ASK.M.SPRollerRowSPtaperedtolerance
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG NN3036ASK.M.SP Double Row Cylindrical Roller Bearing
The FAG NN3036ASK.M.SP is a high-precision double row cylindrical roller bearing designed for demanding industrial applications. With a tapered bore, brass cage, and SP tolerance class, this bearing provides excellent load capacity, durability, and performance in high-speed operations.
Manufacturer: FAG
Type: Double Row Cylindrical Roller Bearing
Model: NN3036ASK.M.SP
| Bore Diameter (d) | 180 mm |
| Outer Diameter (D) | 280 mm |
| Width (B) | 74 mm |
| Dynamic Load Rating | 570,000 N |
| Static Load Rating | 1,000,000 N |
| Fatigue Load Limit | 118,000 N |
| Limiting Speed (Oil) | 3,300 1/min |
| Limiting Speed (Grease Lubrication) | 2,850 1/min |
| Cage Material | M, Brass |
| Bore Designation | K, Tapered, taper 1:12 |
| Tolerance Class | SP |
