Festo 161426 Round Cylinder
Used
In stock1 unitReady to ship
Round Cylinder
The FESTO DSW-32-160PB round cylinder delivers efficient double-acting motion with 160 mm stroke and 32 mm piston diameter, built to ISO 6431 standards for reliable pneumatic applications.1601608161426326431ActingActuatorAluminumCylinderDoubleDSW-32-160PBFestoIndustrialISOmmPneumaticRoundSeriesStroke
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FESTO DSW-32-160PB Round Cylinder
The FESTO DSW-32-160PB Round Cylinder is a high-performance pneumatic actuator designed for reliable motion control. It features a durable aluminum construction, ISO 6431 conformity, and flexible cushioning for smooth operation in industrial automation systems.
Manufacturer: FESTO
Type: Round Cylinder
Model: DSW-32-160PB
Part Number: 161426
Series: 1608
| Stroke | 160 mm |
| Piston Diameter | 32 mm |
| Cushioning | Flexible cushioning rings or plates at both ends (P) |
| Assembly Position | Any |
| Conforms to Standard | ISO 6431 |
| Design Structure | Piston, Piston rod, Cylinder |
| Variants | Single-ended piston rod |
| Operating Pressure | 1 to 10 bar |
| Mode of Operation | Double acting |
| Operating Medium | Dried compressed air, lubricated or unlubricated |
| Corrosion Resistance Classification (CRC) | 2 |
| Ambient Temperature | minus 20 to 80 degree Celsius |
| Theoretical Force at 6 bar, Return Stroke | 415 N |
| Theoretical Force at 6 bar, Advance Stroke | 483 N |
| Pneumatic Connection | G1/8 |
| Materials Information for Cover | Wrought aluminium alloy |
