Festo 175135 Linear Actuator
New
In stock1 unitReady to ship
Linear Actuator
The Festo DGP-32-1000-PPV-A-B-D2 Linear Actuator offers a 1000 mm stroke, 32 mm piston diameter, and 8 bar max pressure. Featuring adjustable pneumatic cushioning, it ensures smooth and precise motion control in industrial applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Festo DGP-32-1000-PPV-A-B-D2 Linear Actuator
The Festo DGP-32-1000-PPV-A-B-D2 Linear Actuator is designed for precise and reliable motion control in industrial applications. With a 1000 mm stroke length and a piston diameter of 32 mm, it is ideal for handling heavy-duty tasks. Featuring pneumatic cushioning, adjustable at both ends, this actuator ensures smooth operation under various working conditions.
Manufacturer: FESTO
Type: Linear Actuator
Model: DGP-32-1000-PPV-A-B-D2
Part No.: 175135
Technical Data:
- Stroke Length: 1000 mm
- Piston Diameter: 32 mm
- Operating Medium: Compressed air
- Cushioning: Pneumatic cushioning, adjustable at both ends
- Guide: Sliding guide, Basic guide
- Max. Operating Pressure: 8 bar
- Mode of Operation: Double acting
- Position Sensing: For proximity sensing
- Pneumatic Connection: G1/8
- Theoretical Force at 6 bar, Retracting: 483 N
- Housing Material: Aluminum anodized
- Temperature: -10 °C … 60 °C
