Festo 18666 Plug Connector
New
In stock1 unitReady to ship
Plug Connector
Festo SEA-GS-7 “ 4-pin, M12x1 A-coded plug connector, 250V AC/DC, 4A, IP67, for robust industrial and automation system applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Festo SEA-GS-7 Plug Connector
The Festo SEA-GS-7 (Part No.: 18666) is a robust and versatile plug connector designed for demanding industrial applications. Supporting both AC and DC voltages up to 250V and a current rating of 4 A at 40°C, this connector provides secure and reliable electrical connections. It features a straight cable outlet and an M12x1 A-coded round plug interface as per EN 61076-2-101 standards. With IP67 protection and a wide ambient temperature range of -40 °C to +85 °C, the SEA-GS-7 is ideal for use in harsh environments.
- Manufacturer: Festo
- Type: Plug Connector
- Model: SEA-GS-7
- Part No.: 18666
Technical Specifications:
- Operating Voltage Range: 0“250V DC / 0“250V AC
- Current Rating at 40°C: 4 A
- Cable Outlet: Straight
- Electrical Connection: M12x1 A-coded, 4-pin (EN 61076-2-101)
- Mounting: Threaded sleeve
- Cable Diameter: 3.3 mm to 6 mm
- Housing Material: PBT
- Housing Colour: Black
- Degree of Protection: IP67
- Ambient Temperature: -40 °C to +85 °C
Applications:
- Industrial automation systems
- Sensor and actuator connections
- Control cabinet integration
- Reliable data and power transmission in harsh environments
