Festo 196032 Round Cylinder
Used
In stock12 unitsReady to ship
Festo DNSU-40-50-PPV-A Round Cylinder “ Double-acting pneumatic cylinder with 40 mm piston and 50 mm stroke. Features G1/4 port, adjustable cushioning, and high-strength materials for automation systems.
40ActingActuatorAdjustableAutomationBarrelCushioningCylinderDNSU-40-50-PPV-ADoubleFestoG1/4HighIndustrialmmPistonPneumaticPneumaticsPressureRoundstainlessSteel
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Festo DNSU-40-50-PPV-A Round Cylinder “ Part No. 196032
The Festo DNSU-40-50-PPV-A is a high-performance round pneumatic cylinder designed for precise motion control in industrial automation systems. With a 40 mm piston diameter and a 50 mm stroke, it features double-acting operation and adjustable pneumatic cushioning on both ends for smooth, controlled performance under high pressure.
Manufacturer: Festo
Type: Round Cylinder
Model: DNSU-40-50-PPV-A
Part No.: 196032
| Piston Diameter | 40 mm |
| Stroke | 50 mm |
| Pneumatic Connection | G1/4 |
| Mode of Operation | Double Acting |
| Operating Medium | Compressed Air |
| Max. Operating Pressure | 10 bar |
| Shape | Circular |
| Cushioning | Pneumatic Cushioning, Adjustable at Both Ends |
| Piston Rod Thread | Male |
| Rod Direction | One Side |
| Material “ Cover | Wrought Aluminum Alloy |
| Material “ Seals | NBR |
| Material “ Piston Rod | High-Alloy Steel |
| Material “ Cylinder Barrel | High-Alloy Stainless Steel |
| Ambient Temperature | -20 to 80 °C |
