Festo 3660619 ISO Cylinder
New
In stock1 unitReady to ship
ISO Cylinder
FESTO DSBC-40-50-D3-PPVA-N3 ISO Cylinder is designed for high-precision pneumatic applications. With a 40 mm bore diameter and a 50 mm stroke, it provides efficient motion control with a 12 bar max pressure. Featuring a G 1/4 pneumatic connection and a male piston rod end, this cylinder is ideal for industrial automation.1/440mm50mmActuatorAutomationboreconnectionControlCylinderdouble-actingDSBC-40-50-D3-PPVA-N3FestoGhigh-pressureIndustrialISOmaleMotionPistonPneumaticRODShapeSquareStroke
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FESTO DSBC-40-50-D3-PPVA-N3 ISO Cylinder
The FESTO DSBC-40-50-D3-PPVA-N3 ISO Cylinder is a high-performance pneumatic actuator designed for precise motion control in industrial applications. Engineered to ISO standards, it offers exceptional durability, efficiency, and reliable performance under high pressure conditions.
Manufacturer: FESTO
Type: ISO Cylinder
Model: DSBC-40-50-D3-PPVA-N3
Part No.: 3660619
| Media | Compressed Air |
| Bore Diameter | 40 mm |
| Stroke | 50 mm |
| Bore x Stroke | 40 x 50 mm |
| Rod Diameter | 15 mm |
| Frame Dimensions | 53 x 183 mm |
| Pneumatic Connection | G 1/4 |
| Pressure Max. | 12 bar |
| Operation Mode | Double |
| Piston Rod End | Male |
| Shape | Square |
| Rod Direction | One Side |
