Festo 573606 Valve Terminal
Used
In stock1 unitReady to ship
Valve Terminal
The FESTO VTUG-14-MSDR-B1T-25V20-Q12-DT-Q6SU-10VK+M1SC Valve Terminal provides efficient air control for industrial automation, offering IP69K protection, 10 bar operating pressure, and durable die-cast aluminum housing.10573606AirAluminumAutomationbarCompressedEVS7FestoIndustrialIP69KPneumaticSeriesterminalValveVTUG-14-MSDR-B1T-25V20-Q12-DT-Q6SU-10VK+M1SC
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FESTO VTUG-14-MSDR-B1T-25V20-Q12-DT-Q6SU-10VK+M1SC Valve Terminal
The FESTO VTUG-14-MSDR-B1T-25V20-Q12-DT-Q6SU-10VK+M1SC Valve Terminal is a high-performance pneumatic unit designed for modular automation systems. It ensures efficient control of compressed air with robust die-cast aluminum construction and high protection standards suitable for harsh industrial environments.
Manufacturer: FESTO
Type: Valve Terminal
Model: VTUG-14-MSDR-B1T-25V20-Q12-DT-Q6SU-10VK+M1SC
Part No.: 573606
| Operating Medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Pilot Medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on Operating and Pilot Medium | Lubricated operation possible |
| Media Temperature | minus 5 to 60 degree Celsius |
| Ambient Temperature | minus 5 to 60 degree Celsius |
| Degree of Protection | IP40, IP65, IP67, IP69K, NEMA 4X |
| Corrosion Resistance Class (CRC) | 2 “ Moderate corrosion stress |
| Vibration Resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock Resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Operating Pressure | minus 0.9 bar to 10 bar |
| Pilot Pressure | 1.5 bar to 8 bar |
| Operating Pressure for Valve Terminal with Internal Pilot Air Supply | 1.5 bar to 8 bar |
| Material Seals | HNBR |
| Valve Terminal Structure | Fixed grid |
| Material | Die cast aluminum |
