Festo 8001200 Pressure Sensor
New
In stock4 unitsReady to ship
Pressure Sensor Industrial FESTO pressure sensor with Io-Link communication, programmable switching outputs, analog output functions, and illuminated display for pneumatic monitoring and automation applications.
AirAnalogAutomationCompressedDigitalElectronicFestoIndustrialIO-LinkIP65M12PneumaticPressureSensorSmart
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Part No. | 8001200 |
| Pressure Measuring Range | -0.1 … 1 MPa |
| Medium | Compressed Air |
| Switching Output | 2 x PNP or 2 x NPN Switchable 2 x PNP |
| Switching Element Function | NC / NO Contact Switchable |
| Analog Output | 0 - 10 V / 4 - 20 mA / 1 - 5 V |
| Output Current Max. | 150 mA |
| Operating Voltage Range | 20 … 30 V DC |
| Display Type | Illuminated LCD / LED |
| Displayable Unit | MPa |
| Io-Link® Protocol Version Device | V 1.1 |
| Io-Link® Profile | Smart Sensor Profile |
| Io-Link® Communication Mode | Com2 (38,4 KBd) |
| Io-Link® Process Data Width Out | 0 Byte |
| Io-Link® Process Data Width In | 2 Byte |
| Io-Link® Process Data Content In | 14 Bit Pdv (Pressure Measurement) / 2 Bit Bdc (Pressure Monitoring) |
| Io-Link® Data Memory Required | 500 Byte |
| Electrical Connection | M12 Connector 4-Pin |
| Material | PA-Reinforced |
| Protection Class | IP65 |
| Medium and Ambient Temperature | 0 … 50 °C |
| Stock Key | JO-004 |
| Condition | New |
| SKU | 1092955 |
| Weight | 1,12 |
