Festo ADVUT-63X2-25-A-P-A Tandem Cylinder
Used
In stock5 unitsReady to ship
Tandem Cylinder
FESTO ADVUT-63X2-25-A-P-A Tandem Cylinder is a high-performance pneumatic actuator designed for precision and reliability. With a 25 mm stroke length, 63 mm x 2 cylinder diameter, and 10 bar maximum pressure, it delivers efficient operation in demanding industrial environments.102563ActingActuatorbarCylinderDoubleFestoHighIndustrialmmPneumaticPrecisionPressureProximitySensingStrokeTandem
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FESTO ADVUT-63X2-25-A-P-A Tandem Cylinder
The FESTO ADVUT-63X2-25-A-P-A Tandem Cylinder is a high-performance pneumatic actuator designed for applications requiring increased force with a compact design. With a double-acting mode of operation and flexible cushioning, it ensures precise movement and reliability in demanding industrial environments.
- Manufacturer: FESTO
- Type: Tandem Cylinder
- Model: ADVUT-63X2-25-A-P-A
- Part No.: 197271
Technical Specifications
- Stroke Length: 25 mm
- Cylinder Diameter: 63 mm x 2
- Piston Rod End: Male
- Max. Operating Pressure: 10 bar
- Mode of Operation: Double Acting
- Cushioning: Flexible cushioning rings/plates at both ends
- Position Sensing: For proximity sensing
- Pneumatic Connection: G1/8
Materials
- Cylinder Tube: Aluminium wrought alloy, smooth anodised
- Piston Rod: High-alloy steel
Operating Conditions
- Temperature Range: -20 … 80 °C
