Festo DNC-50-310-PPV ISO Cylinder
Used
In stock1 unitReady to ship
ISO Cylinder
The Festo DNC-50-310-PPV ISO Cylinder features a 50 mm bore, 310 mm stroke, and square design. With double operation mode and 12 bar max pressure, it delivers precise performance for pneumatic systems.1/41231050ActingActuatorAirAutomationbarboreCompressedconnectionCylinderDNC-50-310-PPVDoubleFestoGIndustrialISOmalemmPneumaticPressureRODShapeSquareStroke
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Festo DNC-50-310-PPV ISO Cylinder
The Festo DNC50310PPV ISO Cylinder is a robust pneumatic actuator designed for high-performance applications. With a 50 mm bore diameter, 310 mm stroke, and durable square shape, it operates with compressed air at pressures up to 12 bar, offering reliable double-acting motion and precise rod control.
Manufacturer: FESTO
Type: ISO Cylinder
Model: DNC-50-310-PPV
Part No.: 163382
| Media | Compressed Air |
| Bore Diameter | 50 mm |
| Stroke | 310 mm |
| Bore x Stroke | 50 x 310 mm |
| Rod Diameter | 20 mm |
| Frame Dimensions | 64 x 450 mm |
| Pneumatic Connection | G 1/4 |
| Pressure Max. | 12 bar |
| Operation Mode | Double |
| Piston Rod End | Male |
| Shape | Square |
| Rod Direction | One Side |
