Electrical Components Industrial Essentials

Finder 55.32.9.024.0074 Push-IN Terminal Socket

Name: FINDER 55.32.9.024.0074 PUSH-IN TERMINAL SOCKET
SKU: 1064010
Availability: LimitedAvailability

finder-55.32.9.024.0074-push-in-terminal-socket-(new)

finder-55.32.9.024.0074-push-in-terminal-socket-(new)-1

finder-55.32.9.024.0074-push-in-terminal-socket-(new)-2

finder-55.32.9.024.0074-push-in-terminal-socket-(new)-3

New

In stock5 unitsReady to ship

Push-In Terminal Socket Finder 55.32.9.024.0074

250 V, 10 A terminal socket with IP20 protection, -40 / 70°C temperature range, and 0.5-2.5 mm² wire compatibility.

Manufacturer

PUSH-IN TERMINAL SOCKET

SKU

1064010

Push-In Terminal Socket Finder 55.32.9.024.0074

The Finder 55.32.9.024.0074 Push-In Terminal Socket is designed for reliable electrical connections. It operates at a rated voltage of 250 V and a current rating of 10 A, making it suitable for various industrial and commercial applications. With an IP 20 protection rating and a wide ambient temperature range, it ensures robust performance even in demanding environments.

Manufacturer: PUSH-IN TERMINAL SOCKET
Type: FINDER
Model: 55.32.9.024.0074
Rated Voltage: 250 V
Current Rating: 10 A
Dielectric Strength: 2 kV AC
Screw Torque: 0.5 Nm
Degree of Protection: IP 20
Ambient Temperature: -40 / 70°C
Wire Strip Length: 10 mm
Wire Size (94.P3 & 94.P4):
- Min. Stranded Wire: 0.5 mm² (21 AWG)
- Max. Stranded Wire: 2 x 1.5 mm² / 1 x 2.5 mm² (2 x 16 AWG / 1 x 14 AWG)
