Finder 8741 0240 0000 Timer
Timer
The Finder 874102400000 Timer offers a time range of 0.05 s to 60 h, 24 to 240 V AC supply, and 6000 V impulse withstand voltage, designed for industrial time control applications with reliable switching performance.Finder 874102400000 Timer
The Finder 874102400000 Timer is a highly versatile timer designed for a wide range of industrial applications. It offers a **time range** from **0.05 s to 60 h** and supports a wide **supply voltage** range of **24 to 240 V AC** and **24 to 48 V DC**. With a **switching type** of **1 Changeover (SPDT)** and a **contact voltage** range of **250 to 440 V AC**, this timer ensures reliable operation. The **IP20 protection degree** ensures durability, and the unit operates efficiently within a **temperature range of -20 to 70 °C**. The **thermal current** is rated at **8 A**, and the timer has a **rated impulse withstand voltage** of **6000 V**, providing excellent protection for industrial environments.
Manufacturer: Finder
Type: Timer
Model: 874102400000
Part No.: 4442879
The Finder 874102400000 Timer is ideal for industrial environments requiring reliable and precise time control, offering durability, flexibility, and high performance in a compact form factor.
| Supply Voltage | 24 to 240 V AC, 24 to 48 V DC |
| Time Range | 0.05 s to 60 h |
| Tightening Torque | 1.2 Nm |
| Switching Type | 1 Changeover (SPDT) |
| Contact Voltage | 250 to 440 V AC |
| Contact Current | 3 A |
| No. of Poles | 1 |
| Thermal Current | 8 A |
| Rated Impulse Withstand Voltage | 6000 V |
| Protection Degree | IP20 |
| Operating Temperature | -20 to 70 °C |
| Dimension | 78.8 x 22.5 x 101 mm |
