Foxboro IGP10-T30E1F-M1L1 Bracket-Mounted Gauge Pressure Transmitter
350,00$
Manufacturer: FOXBORO
Type: Bracket-Mounted Gauge Pressure Transmitter
Model: IGP10
Order Code: IGP10-T30E1F-M1L1
Supply Voltage: 12.5 … 42 V DC
Calibrated range: 0 … 2000 psi
Communication protocol: HART
Output Signal: Intelligent; Digital HART and 4 to 20 mA dc
process connection: 316L ss
Sensor: Nickel alloy (b)
Sensor Fill Fluid: Silicone
Connection Type: 1/2 NPT External Thread, 1/4 NPT Internal Thread
Span Limit: 7 and 210
Conduit Connection and Housing Material: 1/2 NPT Conduit Connection, Aluminum Housing
FM Approvals:
Division 1 intrinsically safe, explosionproof, dust-ignitionproof Zone approved AEx ia IIC Division 2 nonincendive, Classes I, II, and III
Mounting Bracket Set: Painted Steel Bracket with Plated Steel Bolts, 1/2 NPT
Weight: 1.5 kg
