Hager HA404 Main Switch
New
In stock2 unitsReady to ship
Hager Main Switch / Load Break Switch HA 404 with 80 A rated current, 415 V rated voltage, and 12 kA braking capacity. Designed for reliable circuit protection in industrial and residential applications.
12441569080aBrakingBreakBreakerCapacityCircuitCurrentElectricalHagerIEC947-3IndustrialInsulationkALoadMainPolesProtectionRatedSwitchVvoltage
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Hager Main Switch / Load Break Switch HA 404
Hager Main Switch / Load Break Switch HA 404 is designed for reliable circuit protection and load breaking in industrial and residential applications. It offers high performance with excellent braking capacity and insulation, making it suitable for a wide range of electrical systems. Below are the key technical specifications:
- Manufacturer: Hager
- Type: Main Switch / Load Break Switch
- Model: HA 404
- Part No.: 311404
Technical Data:
- Number of Poles: 4
- Rated Current (Ie): 80 A
- Rated Voltage (Ue): 415 V
- Insulation Voltage (Ui): 690 V
- Rated Impulse Withstand Voltage (Uimp): 8 kV
- Braking Capacity (Icc max): 12 kA
- Frequency: 50 to 60 Hz
- Standard: IEC947-3
- Dimensions: 107.5 x 115 x 86.5 mm
