Harting ECON3080-A Ethernet Switch
Manufacture: Harting
Type: Ethernet Switch
Model: ECON3080A
Part No.: 20761083000
Power supply: 24 V DC
Permissible range: 12 V … 30 V DC
Current consumption: 150 mA (at 24 V DC)
Material of housing: Sheet steel (grey painted)
Data rate: 10/100Mbit/s (RJ45)
Maximum cable length: 100 m
Terminating method: RJ45 (Twisted Pair)
No. of ports: 8x 10/100Base-TX, unmanaged
Degree of protection: IP30
Operating temperature: -10 … +70 °C
Dimensions: 23 x 130 x 100 mm
