Hohner 10 11211 Incremental Encoder
199,99$
Hohner 1011211 Incremental Encoder “ Series 10 Precision-engineered incremental encoder with 1000 ppr resolution, solid shaft, IP65 protection, and a robust aluminum housing for industrial motion control applications.
Hohner 1011211 Incremental Encoder “ Series 10
The Hohner 1011211 is a high-precision incremental encoder designed for industrial automation and motion control applications. With a solid shaft, 1000 pulses per revolution (ppr), and IP65 protection, this encoder ensures durability, accuracy, and reliable performance in demanding environments.
Key Details:
Manufacturer: Hohner
Type: Incremental Encoder
Part No.: 1011211
Series: 10
Material Composition:
Environmental Specifications:
The Hohner 1011211 Incremental Encoder is an ideal solution for precise motion control, offering high-resolution feedback, robust mechanical design, and stable signal transmission in automation and industrial applications.
| Shaft Type | Solid Shaft |
| Power Supply Voltage | 11 to 30 V DC |
| Shaft Diameter | 10 mm |
| Revolutions | 1000 ppr |
| Protection Degree | IP65 |
| Signal Output | AB - PP11/28V |
| Connection | Connector |
| Flange | 58 mm round flange with 3 x M3 mm holes |
| Starting Torque | Max. 0.02 N.m |
| Cover | Aluminum |
| Housing | Aluminum |
| Shaft | Stainless Steel |
| Operating Temperature | -20 to +80 °C |
