IFM AC1402 AS-I Profinet Gateway

Manufacturer: IFM

Type: AS-i Profinet gateway

Model: AC1402



Operating voltage [V]: 18…32 DC; (AUX; AS-i: 21…31,6 V DC)

Current consumption [mA]: < 500; (AUX / AS-i 1)
Max. current consumption from AS-i [mA]: 500; (with external supply: 10 mA; AS-i 2: 10 mA)

Number of AS-i masters : 2

Voltage range DC [V]: to PELV

Communication interface: Ethernet

Ethernet – Modbus TCP

Transmission rate: 10 MBaud; 100 MBaud

Connector type: RJ45

Protocol: Modbus TCP

Usage type: programming

Ethernet – PROFINET

Transmission rate: 100 MBaud

Connector type: RJ45

Protocol: PROFINET

Usage type: data transmission

Ambient temperature [°C]: 0 … 60

Protection: IP 20
