IFM II5492 Inductive Sensor
Used
In stock1 unitReady to ship
Inductive Sensor
The IFM II5492 inductive sensor features a 15 mm sensing range, dual PNP/NPN design, and IP67 protection. With normally open/closed outputs, it’s ideal for industrial object detection and automation systems.AutomationClosedifmIIA2015-FRKG/USInductiveIndustrialIP67M30NormallyNPNOpenPNPProximitySensorSwitchThreaded
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
IFM II5492 Inductive Sensor
The IFM II5492 inductive sensor is a versatile and rugged proximity switch designed for precise object detection in industrial environments. With dual PNP/NPN electrical design and both normally open and normally closed output functions, it offers flexible integration and reliable performance.
Manufacturer: IFM
Type: Inductive Sensor
Model: II5492
MNR: IIA2015-FRKG/US
Technical Data:
- Sensing Range: 15 mm
- Operating Voltage: 10 to 55 V DC
- Output Function: Normally Open / Normally Closed
- Max. Voltage Drop (Switching Output DC): 4.6 V
- Permanent Current Rating (DC): 400 mA
- Switching Frequency: 200 Hz
- Electrical Design: PNP / NPN
- Enclosure Rating: IP67
- Housing: Threaded Type
- Ambient Operating Temperature: -25 to 80 °C
- Dimensions: M30 x 1.5, 78 mm
- Material: PBT
