INA LR5206-2Z Track Roller

Manufacturer: Schaeffler INA

Type:  TRACK ROLLER

Model: LR 5206 2Z

Bore Diameter d: 30 mm

Outer Diameter D: 72 mm

Height C: 23.8 mm

Basic load ratings:

Dynamic C_r: 26500 N

Static C_0r: 22000 N

Fatigue load limit C_{ur w}: 1140 N

Speed on permanent grease lubrication: 5500 rpm

Sealing: shield on both sides
