INA Pwkre 80 2RS A Stud Type Track Roller

Manufacturer: INA
Type: Stud type track rollers , full complement cylindrical roller set
Model: PWKRE80 2RS A

Dimensions:
Outside diameter D: 80 mm
Fit diameter of roller stud d₁: 30 mm
Width of the roller stud B: 100 mm
Width of thrust washer B₁: 37 mm
Thread G: M30X1.5
Thread length: 32 mm
Basic load ratings, radial:
Dynamic C_{r w}: 57000 N
Static C_{0r w}: 77000 N
Fatigue load limit C_{ur w}: 10900 N
Speed on permanent grease lubrication: 1800 rpm
Sealing: 2RS, Protected lip seal on both sides
