Intorq BFK458-06E Electric Brake Coil
Spring Applied Brake Coil
High-quality Intorq (Kendrion) / Lenze BFK458 06E brake coil with 205 V DC voltage and 4 Nm rated torque. Compact and durable flange-mounted design for reliable braking performance in industrial automation and motion systems.Intorq (Kendrion) / Lenze BFK458 06E Spring Applied Brake Coil
The Intorq (Kendrion) / Lenze BFK458 06E is a precision-engineered spring applied brake coil designed for reliable stopping performance and consistent torque output in industrial drive systems. It ensures maximum safety and efficiency in motion control applications, ideal for servo motors, gearmotors, and automation equipment that require dependable braking capability.
Manufacturer: Intorq (Kendrion) / Lenze
Type: Spring Applied Brake Coil
Model: BFK458 06E
Serial No.: 00519508
Engineered for durability and precision, this spring applied brake coil delivers smooth operation and strong holding torque even under demanding industrial conditions. Its flange-mounted design ensures quick and secure installation, making it a perfect choice for modern motion systems where reliability, performance, and compact construction are key. Ideal for use in elevators, robotics, conveyors, and automated production lines where accurate braking control is essential.
| Size | 6 |
| Rotor Diameter | 60 mm |
| Rotor Thickness | 6 mm |
| Rated Airgap | 0.2 mm |
| Rated Torque | 4 Nm |
| Brake Max Airgap | 0.5 / 0.3 mm |
| Holding Max Torque | 6 Nm |
| Rated Voltage | 205 V DC |
| Coil Power | 20 W |
| Mounting Type | Flange-mounted |
| Ambient Temperature | -20°C to +40°C |
