Jumo 703031/40-001-000-00-101-01/000 Compact Microprocessor Controller Dtron 08.1

Manufacturer: JUMO

Type: COMPACT MICROPROCESSOR CONTROLLER DTRON 08.1

Model: 703031/40-001-000-00-101-01/000

Voltage: 93 … 263 VAC

Frequency: 48 … 63 Hz

Controller Function: Modulating controller

Input: Pt 100

Output: Relay

Diameter Cable Entry: 13 mm

Current: 3A

Power Rating: approx. 8 VA

Process Value Display: 4-segment display, red

Set Point/Heater Current Display: 4-segment display, green

Ambient Temperature: 0 … +50 °C

Electrical Connection: through faston tabs, 4.8 X 0.8 mm

Protection Class: front IP65, rear IP20

Dimensions: 96 X 48 X 110 mm

Weight: 0.32 Kg
