LANDIS & GYR LGK16.622A17 GAS BURNER CONTROLLER
399,99$
Landis & Gyr Gas Burner Controller LGK16622A17 “ High-quality controller with 100-110 V AC supply, 2 s ignition safety time, and 66 s prepurge time. Built for safe and efficient gas burner operation.
Landis & Gyr Gas Burner Controller LGK16622A17
Manufacturer: Landis & Gyr
Type: Gas Burner Controller
Model: LGK16622A17
The Landis & Gyr Gas Burner Controller LGK16622A17 is a high-quality controller designed for the reliable operation of gas burners in industrial and commercial applications. This controller is engineered to ensure safety, efficiency, and precision, providing dependable control in demanding environments.
Technical Specifications:
- Supply Voltage: 100 to 110 V AC
- Input Current at Terminal 1: 5 A (max)
- Current Rating of Control Terminals: 4 A
- Power Consumption: 3.5 VA
- Pre-fuse (External): 16 A max., slow
- Ignition Safety Time (ts): 2 s
- Prepurge Time with Air Damper Open (tv): 66 s
- Frequency: 50 to 60 Hz
- Operation Temperature: -20 to 60 °C
- Degree of Protection: IP40
- Dimensions: 123 x 103 x 103 mm
Designed for durability and precision, the LGK16622A17 ensures safe ignition and control of gas burners, featuring short ignition safety time and efficient prepurge cycles. With its robust design and reliable performance, this controller is suitable for a wide range of burner systems.
