LC L5110B201000000 Directional Valve
Used
In stock1 unitReady to ship
Directional Valve
The LC L5110B201000000 Directional Valve features NG 6 nominal size, 350 bar pressure, 30 l/min flow, and operates efficiently within -20 to +80 °C fluid temperature range, ideal for hydraulic systems.303506barControlDirectionalflowFluidHydraulicl/minL5110B201000000LCNGRangeSystemTemperatureValveViscosity
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
LC L5110B201000000 Directional Valve
The LC L5110B201000000 Directional Valve is engineered for high-performance applications, providing reliable flow control with a maximum operating pressure of up to 350 bar at P, A, and B ports. It is designed to handle a wide range of fluid temperatures and viscosities for diverse industrial uses.
Manufacturer: LC
Type: DIRECTIONAL VALVE
Model: L5110B201000000
This directional valve offers precise fluid control with a wide range of temperature and viscosity tolerance, making it suitable for demanding hydraulic applications.
| Nominal Size | NG 6 |
| Circuit | 4/3 operated on side B |
| Ambient Temperature | -20 to +50 °C |
| Maximum Operating Pressure (P, A, and B ports) | 350 bar |
| Maximum Operating Pressure at T | 250 bar |
| Maximum Inlet Flow | 30 l/min |
| Fluid Temperature Range | -20 to +80 °C |
| Viscosity Range | 5 to 420 mm²/s |
| Voltage Supply | Without coils |
| Hydraulic Connection | Sub-plate |
