M MC6802P / 1R1H / QLAM9048 Integrated Chip

Manufacturer: M
Type: Integrated Chip
Model: MC6802P
Part No.: 1R1H / QLAM9048

Features:
— 8-Bit Parallel Processing
— Bidirectional Data Bus
— 16-Bit Address Bus – WK Bytes of Addressing
— 72 Instructions – Variable Length
— Seven Addressing Modes – Direct, Relative, Immediate, Indexed, Extended, Implied and Accumulator
— Variable Length Stack
— Vectored Restart
— Maskable Interrupt Vector
— Simplified Clocking Characteristics
— Clock Rates as High as 2.0 MHz
— Simple Bus Interface Without TTL
— Separate Non-Maskable Interrupt – Internal Registers Saved in Stack
— Six Internal Registers – Two Accumulators, Index Register Program Counter, Stack Pointer and Condition Code Register
— Direct Memory Addressing (D MA) and Multiple Processor Capability
