Micro Detectors MVC/A0-0A Photoelectric Sensor

Manufacturer: M.D. Micro Detectors

Type: Photoelectric Sensor

Series: MV

Model: MVC/A0-0A



Function: Retro-Reflective

Nominal Sensing Distance: 4.5 m

Emission: Infrared (880 nm)

No-Load Supply Current: 30 mA

Operating Voltage: 20 … 253 V AC / 50 … 60 Hz

Load Current: 5 … 300 mA

Discrete Output Function: Normally Open

Output Type: TRIAC

Power on Delay: 200 ms

Switching Frequency: 25 Hz

Ambient Temperature: -25 … 70 °C

Degree of Protection: IP67

Connection: Axial Cable Exit 3 Wires

Housing: Plastic

LED: Red

Lenses Material: PMMA

Diameter, Housing Length: M18, 79 mm

Weight: 0.1 kg
